CCS2 to NACS Adapter
VanTon is a professional exporter in China, specialized in electric vehicle products, we pay more attention to product innovation and developing, especially for EV charger products. Our CCS2 to NACS Adapter is one of our most advanced and popular products, designed for users who need safe, efficient, and compatible charging.
With years of experience and continuous innovation, we focus on developing reliable and high-quality EV charger solutions to meet the ever-growing market demands. CCS2 to NACS Adapter is with wide range operating temperature, and special high quality material, we don’t need to worry performance for CCS2 to NACS Adapter. It is safety enough because of various protections, and beautiful line also attracted so many customers.
Compatible For Tesla Car Adaptor
High compatibility: The charging adapter connector can be applied to electric vehicles to ensure the compatibility and stability of charging.
Fast charging: It supports the Supercharger network, which can achieve high-speed fast charging, providing a fast and convenient charging experience for electric vehicles.
Safety performance: It has undergone strict safety testing and certification to ensure safety during use, including protection against problems such as overcurrent, overvoltage and short circuit.
Multiple interface options: With a variety of interface options, it can meet the power standards of different countries and regions, so that electric vehicles can be easily charged around the world.
Details
Parameters
| Product | CCS2 to NACS Adapter |
| Mode | CCS2 to NACS |
| Power | Rated for up to 250kW |
| Rated current | Up to 250A |
| Conductor material | Titanium Copper alloy |
| Shell material | Polyoxymethylene (Insulator inflammability UL94 VO) |
| Operating Temperature | -30℃ to +℃50 |
| Storage Temperature | -30℃ to +℃80 |
| Rated voltage | 500-1000V/DC |
| Security | Single temp, kill switch, Charging stops when adapter reaches 90° |
| C.Sealing gasket | Silicon rubber |
| Security | Anti-Theft Lock |
| Certificate | CE |
| Degree of protection | IP54 |
| Protection from dirt, duct, oil, and other non-corrosive material. Complete protection from contact with enclosed equipment. Protection from water, up to water projected by a nozzle against enclosure from any direction. | |
Features
CE approved for CCS2 to NACS Adapter
Complete protections
High power
Durable material
Ergonomic design
Technical Specifications
| Parameter | Specification | Competitor Benchmark |
| Conductor Material | Aerospace Titanium-Copper | Standard Copper |
| Shell Material | UL94 V0 Fireproof | Basic Plastic |
| Voltage Range | 500-1000V DC (Cybertruck-ready) | ≤800V |
| Seal Technology | Dual-Silicone Gasket | Single Rubber Seal |
| Lifetime Cycles | 10, 000+ (Lab Verified) | ≤5, 000 cycles |
Hot Tags: CCS2 to NACS Adapter
