CCS2 to CHAdeMO Adapter
  • CCS2 to CHAdeMO AdapterCCS2 to CHAdeMO Adapter
  • CCS2 to CHAdeMO AdapterCCS2 to CHAdeMO Adapter
  • CCS2 to CHAdeMO AdapterCCS2 to CHAdeMO Adapter
  • CCS2 to CHAdeMO AdapterCCS2 to CHAdeMO Adapter
  • CCS2 to CHAdeMO AdapterCCS2 to CHAdeMO Adapter

CCS2 to CHAdeMO Adapter

professional supplier of CCS2 to CHAdeMO Adapter, it perfectly solved the incompatibility problem between EV chargers and charging stations, and become reliable partner of our EV car, we can supply you products with competitive price and good quality, it will bring you with a great experience.

CCS2 to CHAdeMO Adapter is acceptable by more and more EV owners, as it’s made by reliable material, then it can be with stable current and long service life. Additionally, beautiful shape line and ergonomical design, it’s really helpful for our using. Hope CCS2 to CHAdeMO Adapter can bring you surprise and excellent experience.

What should we be concerned about?

1: How to do when we find that your adapter can’t charge properly?---To upgrate it.

2: How do choose a suitable DC adatper?--- It depends on the charging socket(car side) and charging station standard.

3: What’s the current needed?---it’s determined by max charging current.

4: How to upgrade the DC adapter?--- Instruction will be supplied, and all the details should be noted.

5: Which style is an ideal one? ---- Normally, lightweight and correct data are our major concerned points.

Parameters

Name CCS2 to CHAdeMO Adapter
Interface standard CCS2 to CHAdeMO
Output current Max 250A
Rated voltage 1000VDCMax
Contact impedance 0.5mΩ Max
Waterproof grade IP54(mating)
Plastic shell Thermoplastic plastic
Working environment -30℃-+50℃
Terminal temperature riseture <50K
Insertion and Extraction Force <140N

Details

CCS2 to CHAdeMO AdapterCCS2 to CHAdeMO AdapterCCS2 to CHAdeMO AdapterCCS2 to CHAdeMO Adapter

Technical parameters

Item Parameters Competitive Product Comparison
Continuous Current 250A DC Industry average 200A
Operating Voltage 1000VDC Supports 800V high voltage platform
Molecular Insertion/Removal Life >10,000 cycles Standard 5000 cycles
Insertion Force ≤130N (measured value) Generally >150N

Core Advantages

Durability Tested

10,000-cycle insertion/removal structure: Utilizes glass fiber reinforced engineering plastic (impact resistance ≥85kJ/m²)

Silver-plated copper terminals: Contact resistance ≤0.5mΩ, ensuring efficiency >99.5% at 250A full current transmission

-30℃ Extreme Cold Test: Tested in Heilongjiang winter, continuous operation for 8 hours without abnormalities

Real-world Compatibility

▸ Tesla Model 3/Y (European CCS2 interface) → Japan CHAdeMO power station (tested charging rate 120kW)

▸ BYD Atto 3 (CCS2) → Thailand IONITY supercharging station (100% compatibility)

Safety Protection

IP54 waterproof in plugged-in state: Withstands heavy rain (50mm/h)

Dual temperature control protection: Automatic current reduction when terminal temperature >80℃ (20℃ safety redundancy above national standard)
